    Electric Driven Marine Propulsion Systems 1380N.m Bronze Azimuth Thruster

    Ask Lasest Price
    Brand Name : Deyuan
    Model Number : DY0201026
    Certification : CCS,ABS,DNV,BV,RINA ..
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 20 sets/month
    Delivery Time : Within 20 to 30 days, According to customers's order
    • Product Details
    • Company Profile

    Electric Driven Marine Propulsion Systems 1380N.m Bronze Azimuth Thruster

    Electric Driven Marine Propulsion Systems 1380N.m Bronze Azimuth Thruster


    Product Feature:


    1. Material:Cu1.Cu3,Copper,bronze.
    2. Certificate:ABS,BV,CCS,DNV GL, KR, LR, NK.
    3. Blades:3-5pcs.


    Specification:


    China Deyuan Marine Fitting Co.,ltd is leading supplier of Tunnel thruster,Marine rudder propeller,marine

    controllable pitch propeller,6 blades marine propeller,79600DWT Bulk Ship Fixed Pitch propeller,fixed

    pitched marine propeller,oil cylinder of adjustable propeller,propeller hub,Pls contact us for more

    specific details.


    We can design and make propellers for container ships,Cargo ships,tankers, and kinds of boats.

    The material can be : Cu1.Cu3,Copper,bronze.

    The dimension can be according to your requirements.

    We are able to make Max 10m diatermeter propeller.

    The blades can be 3.4.5.

    The certificate of ABS,BV,CCS,DNV GL, KR, LR, NK and etc are availabe.


    Type

    Input power Max.(KW)

    Input speed

    rated.(rpm)

    Input torque

    max.(N.m)

    Propeller Dia.max.

    (mm)

    Reduction ratio

    Weight(kg)

    SRP12

    45

    2300

    200

    500

    1.93

    65

    SRP45

    100

    2500

    450

    800

    2.5

    190

    SRP85

    210

    2350

    850

    950

    2.68

    400

    SRP138

    260

    2000

    1380

    1100

    3.01

    1200

    SRP180A

    340

    1800

    1800

    1150

    3.46

    1450

    SRP180B

    280

    1500

    1800

    1150

    2.88

    1450

    SRP180C

    180

    1000

    1800

    1150

    2.526

    1450

    SRP226

    350

    1800

    2260

    1350

    3.34

    2000

    SRP280

    480

    1800

    2800

    1350

    3.96

    2100

    SRP310A

    580

    1800

    3070

    1550

    3.718

    2500


    Quality Control:

    Product Range: We specialized in majority of marine equipments& technique solution.

    Product Design: With strong engineer team, for all marine products, we support design, manufacture, install etc, according to your requirements. All products strictly conform to your confirmation.

    Product Process: Most of products are finished in our manufacture bases, thus quality and delivery time could keep best and , also avoid some details mistake

    Product Inspection: We support factory inspection and inspection/certification.



    Certificates:

    - Material certificates by a classification society
    - Inspection protocol
    - Inspection reports tank testing
    - NDT reports
    - Official certificates for accessories and other equipment


    Advantages of our factory:

    1. Control the product quality from the source
    2. The main mechanical stress components should pass flaw detection to ensure the quality.
    3. Adopt domestic famous brand electric device
    4. Fully equipped with accessories
    5. Easy installation and operation
    6. Provide professional customization service
    7. Reasonable price and good after-sale service
    8. Manufacture according to client's rquirements
