Marine Equipment Rotary Vane Steering Gear Hydraulic Double - Rudder

    Buy cheap Marine Equipment Rotary Vane Steering Gear Hydraulic Double - Rudder from wholesalers

    Buy cheap Marine Equipment Rotary Vane Steering Gear Hydraulic Double - Rudder from wholesalers
    • Buy cheap Marine Equipment Rotary Vane Steering Gear Hydraulic Double - Rudder from wholesalers

    Marine Equipment Rotary Vane Steering Gear Hydraulic Double - Rudder

    Ask Lasest Price
    Brand Name : Deyuan
    Model Number : DY080103
    Certification : CCS,ABS,DNV,BV,RINA ..
    Price : Negotiable
    Payment Terms : L/C, T/T
    Supply Ability : 20 sets/month
    Delivery Time : Within 20 to 30 days, According to customers's order
    • Product Details
    • Company Profile

    Marine Equipment Rotary Vane Steering Gear Hydraulic Double - Rudder

    Marine Equipment Rotary Vane Steering Gear Hydraulic Double - Rudder
    Marin advantages:

    1. Electro-hydraulic control.
    2. Compact design.
    3. Suitable for normal rudder blades.
    4. Pumps with variable displacement or constant delivery.
    5. One-piece tiller for standard or keyless fit of rudder stock.
    6. pump units mounted on and completely piped with the cylinders.


    Specification:

    1) Suitable for:
    Containers, tankers, ferries, General cargo ships, passage ships, Dredgers and any other vessels that
    need more steering torque.

    (2) Main Tech:
    Max working torque: 15 KN.M — 250 KN.M
    Max. mech. rudder angle: ± 45 degree
    Time of rudder movement: ≤28 S
    Rudder stock Diameter: 300mm — 900 mm
    Working pressure: 13 Mpa — 20 Mpa
    Design pressure: 16 Mpa — 24 Mpa

    (3) Scope of delivery:
    Marine steering gear with hydraulic cylinders
    Electro-Hydraulic power station with oil pumps
    Oil tanks
    Start motors
    On requests, the full range of parts will be delivered.

    (kn.m)
    Nominal Torque

    Turning
    Angle
    (°)

    Turning time(s)

    Rated power
    (kw)

    Dimension (mm)

    A

    B

    C

    D

    F

    G

    DY63

    35

    28s/65°

    5.5

    2470

    2320

    505

    350

    380

    694.5

    DY100

    35

    28s/65°

    7.5

    2718

    2500

    505

    400

    420

    704.5

    DY160

    35

    28s/65°

    11

    2996

    2740

    505

    450

    420

    704.5

    DY200

    35

    28s/65°

    15

    3304

    3020

    505

    500

    550

    726.5

    DY250

    35

    28s/65°

    15

    3630

    3160

    505

    550

    550

    726.5

    DY320

    35

    28s/65°

    18.5

    3938

    3400

    505

    600

    550

    726.5

    DY400

    35

    28s/65°

    18.5

    3914

    3600

    560

    570

    600

    950

    DY450

    35

    28s/65°

    18.5

    4000

    3600

    560

    570

    600

    950

    DY500

    35

    28s/65°

    18.5

    4000

    3600

    560

    570

    600

    950



    Quality Control:

    Product Range: We specialized in majority of marine equipments& technique solution.

    Product Design: With strong engineer team, for all marine products, we support design, manufacture, install etc, according to your requirements. All products strictly conform to your confirmation.

    Product Process: Most of products are finished in our manufacture bases, thus quality and delivery time could keep best and , also avoid some details mistake

    Product Inspection: We support factory inspection and inspection/certification.



    Certificates:

    - Material certificates by a classification society
    - Inspection protocol
    - Inspection reports tank testing
    - NDT reports
    - Official certificates for accessories and other equipment


    Advantages of our factory:

    1. Control the product quality from the source
    2.The main mechanical stress components should pass flaw detection to ensure the quality.
    3. Adopt domestic famous brand electric device
    4. Fully equipped with accessories
    5. Easy installation and operation
    6. Provide professional customization service
    7. Reasonable price and good after-sale service
    8. Manufacture according to client's rquirements
