Shipping container parts Loose fitting in hold bridge fittings

Description:

Container secuing systems are composed with various lashing devices through a certain way to secure a containers during transpotations,the systems surely insure the security of transpotation.

Our mainly products for container spare parts as following:

Fixed fittings on deck: Raised foundations, Dovetail foundations, Lashing plates, D-rings .

Fixed fittings in holds: Flush type twistlock pockets, Welding plates, Welding cones, Guide fittings

Loose fittings on deck: Semi-automatic twistlocks, Conventional twistlocks, Midlocks, Dovetail twistlock, Turnbuckles (Pluse spanner) , Lashing bars ( pluse extension rods) , Operating rods , Bin racks , Storage bins , Bridge fittings ( pluse spanner )

Loose fittings in holds : Twist/double stackers, Stacking cones, Bottom stacking cones, pressure tension elements, Bridge fittings, base stacking cone, safety stacking cone, hanging stacking cone

Tension Type container bridge fittings specification:

1. Connects two containers side by side
2. Hooks-drop forged steel
3. Finish hot dip galvanized
4. Breaking load: 100KN
5. Compatible with all ISO type containers
6. Dimensions: 260mm, 280mm, 330mm, 380mm

7. Certificate:GL,BV,CCS,ABS,RINA,LR,NK,DNV etc.

Tension and Pressure Type Container Bridge Fittings

1. Finish hot dip galvanized

2. Breaking load: 250KN

3. Compatible with all ISO type containers

4. Other Lengths Available

The pictures as follows :

Drawings:

We also supply other items below:

Factory workshop:

Zhuhai City Deyuan Import&Export Co., Ltd is a subsidiary company of China deyuan marine fitting Co., Ltd, .

We are the leading and trusted supplier of marine equipment and offshore equipment in the marine market of China.

We do export business globally in the market for many years and export lots of marine equipment to different countries. Our target is to be the best alternative for the customer's bottom line in the long perspective and always put good quality, good service in the first place. Because of that, we win high appreciation from our customers and have high reputation in this field

Our products include:

Marine life saving equipment: (immersion suit, life boat, inflatable boat, life raft, life jacket, life jacket light etc)

Marine fire fighting equipment: (FIFI system, SCBA, EEBD, fire suit, heat insulation suit, fire extinguisher etc)

Environment Protection Equipment: (Oily water separator, sewage treatment plant, fresh water generator, UV-sterilizer etc)

Marine Mooring Equipment: (marine anchor, anchor chain etc)

Marine Power&Propulsion Equipment: (Tunnel thruster, marine propeller, marine shaft etc)

Marine Deck Equipment: (Marine Windlass, Marine Winch, Marine Davit)

Marine Diesel engine: (CUMMINS Diesel engine, Weichai diesel engine, Deutz diesel engine)

These products are SOLAS compliant, approved by different Classification Society, such as ABS, BV, KRNK, GL, LR, RINA, CCS, DNV, IRS. Pls contact us for more information or just send yr inquiry to us.

We are very confident that our ethusiasam and profession, integrerity will earn your trust.
